ROACH 3-way Splitter discrete buffers in a small package. Studio quality specifications with simple straight forward operation.
The ROACH is a mini sized 3-way splitter discrete Class-A buffered outputs. Due to its size, only powers via the DC inlet and has a wide acceptance, 9-24vdc. MOSFET input protects if the wrong orientation adaptor is connected, no more damage internally. LED is clear high-bright green. Proudly made in North America.
Pedal size (W/D/H): 3.642″(92.51mm) x 1.516″(38.51mm) X 1.220″(30.99mm)
Shipping Weight: 250g
DC Adapter (not included): 9-24VDC, Center Pin Negative (Regulated)
Power supply only, no battery operation
Current draw: @9VDC ~ 4mA
Input ~1M / Output ~10K min. load
Frequency response: 20hz to 20khz
Max output: +9dBm(9VDC), +18dBm(24VDC)
Pricing in $USD
